FV Sub-HEPA Filter, Low Resistance Polypropylene Air Filter for Compact HVAC System

FV-Combined Sub-HEPA Air Filter

FV-Combined Sub-HEPA Air Filter

Design Features：

Adopts high-quality PP ultra-fine polypropylene filter media
Polypropylene plastic frame, produces no toxic gas when incinerated after disposal
Large filtration area, low air resistance and long service life
Overall depth of 292mm, ideal for ventilation and air conditioning systems with limited installation space
Equipped with mounting flange frame, interchangeable with conventional pocket filters

Technical Parameters：

Model	Overall Dimensions（mm）			Rated Air Flow（m3/h)	Initial Resistance（Pa)	Efficiency（%）	Material
	W	H	D				Filter Media	Separator	Sealant	Frame Material
FV	595×595×295			3600	≦100	95%	Ultra-fine PP Polypropylene	Hot Melt Adhesive	Polyurethane Adhesive	Polypropylene
	296×592×295			1800

Notes：Custom specifications are available. Slight color difference between product images and actual goods may exist, please refer to the delivered products.
